MLWF800- With Ash Bucket-7.5kw-air volume 10500m³/h

product details

  • Product Profile


    The centralized smoke and dust purification system consists of dust collecting cover, pipeline, main engine, fan and smoke exhaust pipe. When running, the suction generated by fan collects the smoke and dust from workshop to pipeline system through dust collecting cover, and then transports the smoke and dust to the main engine through pipeline for filtering and purification. The purified air is discharged directly into the outdoor.This can reduce the damage to the surrounding air environment and accelerating the diffusion of pollutants.

    Application: Multi-station welding, laser cutting, grinding such as grinding iron chips, stone, furniture dust, etc.


    Product characteristics


    · Integral structure, beautiful appearance, small area;

    · Anti-suction device, more thoroughly cleaning effect;

    · Power supply monitoring: Alarm for broken phase overvoltage and undervoltage to prevent motor and electrical components     from being damaged;

    · Barometric monitoring:Alarm for low air pressure to prevent incomplete ash cleaning

                           Pressure differential gauge shows the usage of filter element

                           Automatic Pulse Back Blowing of Excessive Pressure Difference

    · Operation temperature monitoring: Alarm system for high temperature  to prevent fire
